3. When using the MEWTOCOL master function in UDP, BROADCAST communication
Set as follows for each unit using Configurator WD.
IP address setting
Communication setting
Option setting
Master unit IP address: 192.168.1.5
Netmask: 255.255.255.0
Gateway: 192.168.1.1
Communication protocol: UDP
Action mode: Client connection
Baud rate: 115200 bps
Communication mode:
Computer link
Send type: BROADCAST
Destination IP address:
192.168.1.11
Destination port No.: 9094
Source port No.: 0
Not necessary.
Slave unit 1
IP address: 192.168.1.11
Netmask: 255.255.255.0
Gateway: 192.168.1.1
Communication protocol: UDP
Action mode: Server connection
Baud rate: 115200 bps
Communication mode:
Computer link
Send type: BROADCAST
Source port No.: 9094
Not necessary.
Slave unit 2 IP address: 192.168.1.2
Netmask: 255.255.255.0
Gateway: 192.168.1.1
Communication protocol: UDP
Action mode: Server connection
Baud rate: 115200 bps
Communication mode:
Computer link
Send type: BROADCAST
Source port No.: 9094
Not necessary.
