Range setting switch
Select the thermocouple type K or J with the switch at the back. (The CH0 and CH1 will be the same
range.)
Switch (backside)
Thermocouple type K
Thermocouple type J
K and J range
Conversion characteristics graph
When exceeding the rated range
Input value
Converted value
-50.1
°
C or less
K –501
500.1 °C or more K 5001 or K 8000
When wire is broken
K 8000
