Item
Description
Vibration resistance
5 to 9 Hz, single amplitude of 3.5 mm, 1 cycle/min
9 to 150 Hz, constant acceleration of 9.8 m/s
2
, 1 cycle/min, 10 min on 3 axes
Shock resistance Shock of 147 m/s
2
, 4 times on 3 axes
Noise
immunity
AC
1500 Vp-p with pulse widths 50 ns and 1µs (based on in-house
measurements) (AC power supply terminal)
DC
1000 Vp-p with pulse widths 50 ns and 1µs (based on in-house
measurements) (DC power supply terminal)
Operation condition
Free from corrosive gases and excessive dust
Conformed EC
directive
EMC: EN61131-2, LVD: EN61131-2
Overvoltage category
Category II
Pollution level Pollution level 2
Note1) Not isolated between the tool port, USB port, Analog input cassette and Communication cassette
(RS232C part).
Note2) Cutoff current: 5 mA (Factory default setting)
Note3) Excluding between the Analog input cassette, Communication cassette (RS232C part) and
protection earth terminal.
Note4) Excluding between the input terminal and the output terminal of the pulse I/O cassette.
Power supply specifications
AC Power Supply
Item
Specifications
C14
C30/C60
E30
Rated voltage
100 to 240 V AC
Voltage regulation range 85 to 264 V AC
Inrush current
(at 240 V AC, 25
°
C)
40 A or less 45 A or less 40 A or less
Momentary power off time 10 ms (when using 100 V AC)
Frequency
50/60 Hz (47 to 63 Hz)
Leakage current 0.75 mA or less between input and protective earth terminals
Internal power supply part
Guaranteed life
20,000 hours (at 55 °C)
Fuse Built-in (Cannot be replaced)
Insulation system
Transformer insulation
Terminal screw M3
Service Power Supply for Input (Output) (Used for AC power supply type only)
Item
Specifications
C14
C30/C60/E30
Rated output voltage
24 V DC
Voltage regulation range 21.6 to 26.4 V DC
Rated output current
0.15 A
0.4 A
Overcurrent protection
function
Note)
Available
Terminal screw
M3
Note) This is a function to protect overcurrent temporarily. If a current load that is out of the
specifications is connected, it may lead to damages.
