Panasonic AFPX-C30T - Power supply specifications

DC power supply
Item
Specifications
C14
C30/C60
Rated voltage 24 V DC
Voltage regulation range
20.4 to 28.8 V DC
Inrush current 12 A or less (at 25 °C)
Momentary power off time
10 ms
Internal power supply part
Guaranteed life
20,000 h (at 55 °C)
Fuse
Built-in (Cannot be replaced)
Insulation system Transformer insulation
Terminal screw
M3
Weight
Unit
Model No.
Weight
Unit
Model No.
Weight
Control
unit
AFPX-C14R
Approx. 280 g
FP-X
Communi-
cation
cassette
COM1
AFPX-COM1
Approx.
20 g
AFPX-C14RD Approx. 260 g COM2 AFPX-COM2
AFPX-C14T
Approx. 270 g
COM3
AFPX-COM3
AFPX-C14TD
Approx. 250 g
COM4
AFPX-COM4
AFPX-C14P
Approx. 270 g
COM5 AFPX-COM5
Approx.
25 g
AFPX-C14PD
Approx. 250 g
AFPX-C30R
Approx. 490 g
COM6 AFPX-COM6
Approx.
20 g
AFPX-C30RD
Approx. 470 g
AFPX-C30T
Approx. 460 g
Analog input cassette
AFPX-AD2
Approx.
25 g
AFPX-C30TD
Approx. 440 g
Analog output
cassette
AFPX-DA2
AFPX-C30P
Approx. 460 g
AFPX-C30PD
Approx. 440 g
Analog I/O cassette
AFPX-A21
AFPX-C60R
Approx. 780 g
Thermocouple
cassette
AFPX-TC2
AFPX-C60RD
Approx. 760 g
AFPX-C60T
Approx. 700 g
RTD cassette
AFPX-RTD2
AFPX-C60TD
Approx. 680 g
Input cassette
AFPX-IN8
AFPX-C60P
Approx. 700 g
Output cassette
AFPX-TR8
AFPX-C60PD
Approx. 680 g
AFPX-TR6P
Expansion
I/O unit
AFPX-E16X
Approx. 190 g
I/O cassette
AFPX-IN4T3
AFPX-E14YR
Approx. 230 g
Pulse I/O cassette
AFPX-PLS
AFPX-E16R
Approx. 195 g
Master memory
cassette
AFPX-MRTC
Approx.
20 g
AFPX-E16T
Approx. 180 g
AFPX-E16P
Approx. 180 g
FP-X backup battery
AFPX-BATT
Approx. 7 g
AFPX-E30R
Approx. 470 g
AFPX-E30RD
Approx. 450 g
AFPX-E30T
Approx. 430 g
AFPX-E30TD
Approx. 410 g
AFPX-E30P
Approx. 430 g
AFPX-E30PD
Approx. 410 g
Expansion
FP0
adapter
AFPX-EFP0 Approx. 65 g
