Panasonic AFPX-C30T - Units current consumption table

Unit’s current consumption table
Unit type
Current consumption of power supply for
Control unit
100 V AC
200 V AC
24 V DC
Control unit
AFPX-C14R
185 mA or less
130 mA or less
―
AFPX-C14RD
―
―
235 mA or less
AFPX-C30R
410 mA or less
260 mA or less
―
AFPX-C30RD
―
―
360 mA or less
AFPX-C60R
540 mA or less
320 mA or less
―
AFPX-C60RD
―
―
550 mA or less
AFPX-C14T
160 mA or less
110 mA or less
―
AFPX-C14P
160 mA or less
110 mA or less
―
AFPX-C30T
360 mA or less
225 mA or less
―
AFPX-C30P
370 mA or less
230 mA or less
―
AFPX-C60T
370 mA or less
230 mA or less
―
AFPX-C60P
380 mA or less
240 mA or less
―
AFPX-C14TD
―
―
160 mA or less
AFPX-C14PD
―
―
160 mA or less
AFPX-C30TD
―
―
200 mA or less
AFPX-C30PD
―
―
210 mA or less
AFPX-C60TD
―
―
250 mA or less
AFPX-C60PD
―
―
290 mA or less
Expansion I/O unit
AFPX-E16R
Note1)
65 mA or less
40 mA or less
145 mA or less
AFPX-E30R
Note2)
310 mA or less
210 mA or less
―
AFPX-E30RD
―
―
320 mA or less
AFPX-E16T
Note1)
20 mA or less
10 mA or less
60 mA or less
AFPX-E16P
Note1)
30 mA or less
15 mA or less
90 mA or less
AFPX-E30T
Note2)
345 mA or less
220 mA or less
―
AFPX-E30P
Note2)
350 mA or less
225 mA or less
―
AFPX-E30TD
Note2)
―
―
170 mA or less
AFPX-E30PD
Note2)
―
―
220 mA or less
AFPX-E16X
20 mA or less
10 mA or less
35 mA or less
AFPX-E14YR
75 mA or less
40 mA or less
210 mA or less
Communication
cassette
AFPX-COM1
Note1)
AFPX-COM2
Note1)
10 mA or less 10 mA or less 10 mA or less
AFPX-COM3
Note1)
AFPX-COM4
Note1)
15 mA or less 10 mA or less 15 mA or less
AFPX-COM5
Note1)
30 mA or less
20 mA or less
75 mA or less
AFPX-COM6
Note1)
15 mA or less
10 mA or less
15 mA or less
Applica-
tion
cassette
Note)
Analog input
cassette
AFPX-AD2
Note1)
10 mA or less 10 mA or less 15 mA or less
Analog output
cassette
AFPX-DA2
Note1)
50 mA or less 30 mA or less 120 mA or less
Analog I/O
cassette
AFPX-A21
Note1)
30 mA or less 20 mA or less 70 mA or less
Thermocouple
cassette
AFPX-TC2
Note1)
10 mA or less 5 mA or less 25 mA or less
RTD cassette
AFPX-RTD2
Note1)
20 mA or less
10 mA or less
35 mA or less
Input cassette
AFPX-IN8
Note1)
10 mA or less
5 mA or less
10 mA or less
Output cassette
AFPX-TR8
Note1)
10 mA or less
5 mA or less
10 mA or less
Output cassette
AFPX-TR6P
Note1)
10 mA or less
5 mA or less
30 mA or less
I/O cassette
AFPX-IN4T3
Note1)
10 mA or less
5 mA or less
10 mA or less
Pulse I/O
cassette
AFPX-PLS
Note1)
10 mA or less 10 mA or less 15 mA or less
Master memory
cassette
AFPX-MRTC
Note1)
10 mA or less 10 mA or less 10 mA or less
Programmable display
GT01,GT01R
(5 VDC,RS232C)
25 mA or less 15 mA or less 80 mA or less
