Note1) These current consumption indicate the increased amount of the current consumption of the
Control unit (refer to the example of the calculation below).
Note2) The current consumption of E30 is the current consumption at the supply terminal of E30. The
current consumption of the control unit does not increase.
Unit type
Current consumption
24 V DC
Expansion FP0 adapter AFPX-EFP0 10 mA or less
[Example of calculation] (when 100 V AC)
C30R
+
IN8
+
TR8
+
E16R
+
EFP0
410 mA 10 mA 10 mA 65 mA 10mA + Current consumption of FP0
expansion unit
Total 495 mA or less (100 V AC) 10mA + Current consumption of FP0
expansion unit (24V DC)
Example: When one FP0 expansion unit
(FP0-E32T) is connected:
FP0 expansion adapter: 10 mA or less
+ FP0-E32T: 40 mA or less
⇒ total 50 mA or less
