C14 C30 C60 C14 C30 C60
Pulse
output/
PWM output
Note4)
Input of main
unit
None
C14: 3 chs (High-speed 2 chs, medium-
speed 1 ch)
C30/C60: 4 chs (High-speed 2 chs,
medium-speed 2 chs)
Pulse: With high-speed 2 chs (100 kHz
each)
For linear interpolation, composite
speed: 100 kHz
With medium-speed 2 chs (20 kHz
each)
For linear interpolation, composite
speed: 20 kHz
PWM:
High-speed: 1.5 Hz to 41.7 kHz
Medium-speed: 1.5 Hz to 15.6 kHz
1000 resolution (12.5 kHz or less),
100 resolution (over 12.5 kHz)
Pulse I/O
cassette is
installed
C14: 1 ch
C30/C60: 2 chs when 2 cassettes are
installed.
Pulse: with 1 ch (100 kHz), with 2 chs
(80 kHz each)
PWM: 1.5 Hz to 41.7 kHz
1000 resolution (12.5 kHz or less), 100
resolution (over 12.5 kHz)
Pulse I/O cassette cannot be installed.
Pulse catch input/interrupt
input
14 points
(Input of main unit: 8 p oints X0 to X7,
Pulse I/O cassette: 3 points x 2)
8 points
(Input of main unit: 8 p oints X0 to X7)
Periodical interrupt 0.5 ms to 30 s
Potentiometer (Volume)
Constant scan Available
Realtime clock
Available (year, month, day, hour, minute, second and day of week) (However, this
can only be used when AFPX-MRTC and an optional battery has been installed.)
Note5)
Counter 16 points (C1008 to C1023)
Note10)
, internal relay 128 points (WR248 to
WR255), data register 55 words
Battery backup
Memory that is set as hold area at system register (However, only when an
optional battery has been installed.)
Note7)
Battery
life
Note8)
When AFPX-
MRTC is not
installed
C14: 3.3 years or more
C30/C60: 2.7 years or more
When AFPX-
MRTC is
installed
C14: 2.1 years or more
C30/C60: 1.8 years or more
Note) More than 2 batteries can be installed. In that case, the battery life is the
value multiplied by the No. of batteries.
