PACD011001C2 Test Operation
Test Operation Urban Multi “MX1, ME1 Series” Using R-22 129
Control Section
1 Clock adjusting button 6 Timer ON button
Push to set the present time. Sets the present time or programmed time.
2 Button for selecting days of a week 7 Hour/minute button
Push when selecting days of a week. Push to adjust the present time or programmed time.
3 Holiday setting button 8 Programming start button
Sets holiday. Push to set or check No. of programmed time. After completion,
push again.
4 Button for copying programs of previous day 9 Clock adjusting button
Sets to same No. of programmed time as previous day. Push to set the present time.
5 Program canceling button
Cancels programmed time and sets display to [ — : — —].
To Next Page
