4.3.17. Scanned Copy Quality Problems
START
No
Yes
Is the Xenon Lamp abnormal?
Replace the Xenon Lamp.
END
Are the Transmitting
Rollers dirty?
Are there any foreign particles
or paper pieces in the scanning
area?
Yes
No
Remove the foreign particles or paper
pieces from the scanning area.
No
Yes
Is the scanning area dirty?
1. Clean the Scanning Glass.
2. Clean Mirrors 1 and 2.
No
Yes
Clean the rollers.
Is the Scanner Block abnormal?
1. Check CN (SC PCB).
2. Check CN (CCD PCB).
3. Replace the CCD Assembly.
4. Replace the SC PCB.
Yes
No
