Panasonic KX-TDA50

Service Description Details in
Caller ID The PBX receives Caller ID information, such as
the caller
’s name and telephone number, when a
call is sent from the network. A display proprietary
telephone (PT) user can see this information
before answering the call.
® 3.1.1 Caller ID
3. Private Networking Connection (QSIG)
Private
networking with QSIG is possible using an ISDN line. Each ISDN port must be programmed so that
each ISDN line has a "master" connection and a "slave" connection.
Conditions
• En bloc
The PBX sends all of dialed digits at once after the extension user completes dialing. The PBX recognizes
the end of dialing as follows:
– the # key is pressed (programmable).
4.17 [2-9] System Options—Option 2—
End of Dial Plan—[#] as End of Dial for en Bloc mode
(KX-TDA100/KX-TDA200/KX-TDA600 only)
– the dialed number is a preprogrammed telephone number.
5.4 [3-1-4] Dialing Plan
– the inter-digit timer expires.
4.4 [2-3] Timers & Counters—Dial / IRNA / Recall / Tone—
Dial—Extension Inter-digit
• Extension Number
An extension number can be assigned to each ISDN port.
6.1 [4-1-1] Wired Extension—Extension Settings
—Main—
Extension Number
• Network Type
Each ISDN port can be set to the requirements of each country/area.
• L1 Active Mode and L2 Data Link Mode
The active mode of Layer 1 (L1) and the data link mode of Layer 2 (L2) can be selected individually
(Permanent or Call by Call) for each ISDN port.
• TEI Assignment Mode
The Terminal Endpoint Identifier (TEI) assignment mode can be selected for each ISDN port.
• Bearer Mode
The bearer mode can be assigned for each ISDN port.
6.1 [4-1-1] Wired Extension—Extension Settings
—Option 6—
ISDN Bearer (KX-TDA100/KX-TDA200/
KX-TDA600 only)
6.10 [4-2-1] Portable Station—Extension Settings
—Option 6—
ISDN Bearer
PC Programming Manual References
3.13 [1-1] Slot—Card Property - PRI type (KX-TDA100/KX-TDA200/KX-TDA600 only)
3.14 [1-1] Slot—Port Property - PRI Port (KX-TDA100/KX-TDA200/KX-TDA600 only)
3.15
[1-1] Slot—Port Property - PRI Port—Connection Command (KX-TDA100/KX-TDA200/KX-TDA600 only)
4.4 [2-3] Timers & Counters—Dial / IRNA / Recall / Tone—
Dial—Extension Inter-digit
4.17
[2-9] System Options—Option 2—
End of Dial Plan—[#]
as End of Dial for en Bloc mode (KX-TDA100/
KX-TDA200/KX-TDA600 only)
6.1 [4-1-1] Wired Extension—Extension Settings
→Main—
Extension Number
→Option 6— ISDN Bearer (KX-TDA100/KX-TDA200/KX-TDA600 only)
6.10 [4-2-1] Portable Station—Extension Settings
—Option 6—
ISDN Bearer
5.5 [3-1-4] Dialing Plan
—Auto Assign
Document Version 2010-11 Feature Manual 175
9.1.16 ISDN (INTEGRATED SERVICES DIGITAL NETWORK) FEATURES
