Panasonic KX-TDA50

KX-TDA100/KX-TDA200
2.5.8 IP-EXT16 Card (KX-TDA0470)
KX-TDA600
2.7.8 IP-EXT16 Card (KX-TDA0470)
PC Programming Manual References
3.22 [1-1] Slot—Card Property - IP Extension
3.24 [1-1] Slot—Port Property - IP-Extension Port
9.1.16 ISDN (INTEGRATED SERVICES DIGITAL NETWORK)
FEATURES
Description
Integrated Services Digital Network (ISDN) is a digital switching and transmission network. ISDN transmits
voice, data, and image in digital format. ISDN lines can be connected to public lines (CO lines), private lines
(QSIG).
ISDN Service features are only available for
KX-TDA100, KX-TDA200, and KX-TDA600.
1. ISDN Interface and Configuration
Interface Type Description Port Mode
Primary Rate Interface
(PRI)
Provides twenty-three 64 kbps B channels for
communication and one 64 kbps D channel for
signaling (23B + D).
CO Line, QSIG—
Master, QSIG—
Slave
*1
*1
3.14 [1-1] Slot—Port Property - PRI Port (KX-TDA100/KX-TDA200/KX-TDA600 only)—Main
—
Port
2. ISDN Supplementary Services for Public Network
Service Description Details in
Direct Inward Dialing
(DID)
Directs a call with a DID number to the
preprogrammed destination.
®
4.1.5 DID (Direct
Inward Dialing)
Calling Line
Identification
Presentation (CLIP)
Sends the caller’s telephone number to the
network
when making a call. The called party can
see the number on his or her telephone display
before answering the call.
® 3.1.13 CLIP
(Calling Line
Identification
Presentation)
Connected Line
Identification
Presentation (COLP)
Sends the telephone number of the answered
party to the network when answering a call. The
caller can see the number on his telephone
display when the line is connected.
Calling Line
Identification
Restriction (CLIR)
Prevents the caller’s
CLI from being presented to
the called party.
Connected Line
Identification
Restriction (COLR)
Prevents COLP from being sent by the answered
party.
174 Feature Manual Document Version 2010-11
9.1.16 ISDN (INTEGRATED SERVICES DIGITAL NETWORK) FEATURES
