13.1.20 Private Network Features—QSIG—CF (Call Forwarding)
Description
The
PBX forwards the call to a destination extension in another PBX in the QSIG network. The destination can
be set on your own PBX on an extension basis as the forward destination of CO line calls (® 6.1.6 FWD (Call
Forwarding)).
If the same trunk group is used for the incoming call and the forwarded call, the following situation will be
possible.
[Example]
PBX-1
QSIG
PBX-2
Dials "2000".
PBX-1
QSIG
PBX-2
Extn. 1001 Extn. 2000
Extn. 1001 Extn. 2000
(Forward Destination
of CO Line Calls: 1001)
Call to 2000
1
Forwarded
to 1001
2
3
Extn. 1000
Extn. 1000
Extension 1000 of PBX-1 dials
extension number
"2000", and the call
is sent to extension "2000" of PBX-2
through QSIG network.
The call is forwarded to the forward
destination
of CO line calls of extension
2000, which is extension "1001" of
PBX-1.
The call between PBX-1 and PBX-2 is
released, and the call is connected
directly to the forward destination of
extension 2000.
Conditions
• This feature can be enabled or disabled on each ISDN (QSIG) port of the PBX.
PC Programming Manual References
3.14 [1-1] Slot—Port Property - PRI Port (KX-TDA100/KX-TDA200/KX-TDA600 only)—Supplementary
Service—
COLP, CLIR, COLR, CNIP, CONP, CNIR, CONR, CF (Rerouting), CT, CCBS, E911
3.35
[1-3] Option—
New Card Installation—ISDN
Standard Mode for PRI23 Card (KX-TDA100/KX-TDA200/
KX-TDA600 only)
Document Version 2010-11 Feature Manual 259
13.1.20 Private Network Features—QSIG—CF (Call Forwarding)
