[Example]
PBX-1
TIE Line Network
TIE Line
PBX-2
Extn. 2011
Outside Caller
CO Line
CO Line
Interface
Dials "123-4567".
Telephone Company
Destination: 2011
DID No: 4567
Interface
Extn. 1011
Explanation:
An outside caller dials
"123-4567". The call is sent to extension "2011" of PBX-2 through the TIE line
according to the assignment of the DID or DIL call destination of PBX-1. (® 4.1.5 DID (Direct Inward
Dialing))
12.3 [10-3] DID Table—
DID Destination—Day, Lunch, Break, Night
[453] DID Destination
b. FWD/Call Transfer/Intercept Routing to the TIE Line
[Example]
TIE Line Network
TIE Line
Forwarded/Transferred
/Intercepted to 7-952-2011
Extn. 2011Extn. 1011
Outside Caller
CO Line
CO Line
Interface
Dials "123-4567".
Telephone Company
Interface
PBX-1
PBX-2
PBX Code 952PBX Code 952
226 Feature Manual Document Version 2010-11
13.1.13 PRIVATE NETWORK FEATURES
