Focus / Zoom – Using AF
164
[SET]
1 Use the same procedure as MF (Record Using MF: 197) to check the
focus, then press [WB] or [ISO] to set the range of operation for AF.
• This can also be set by touching [Limit1]/[Limit2].
• [Limit1]/[Limit2] can be set from either.
2 Press or to confirm the setting.
• Press [DISP.] to return the operation range to the default setting.
• This can be set when using a lens with a focus ring or a focus lever.
• It cannot be set if the focusing distance range selector switch of the lens has
been used to limit the operation range.
• The setting values are reset when the lens is replaced.
• When [Focus Limiter] is working, [ ]/[ ] is displayed on the screen.
• When the following function is being used, [Focus Limiter] is not available:
– [AF+MF]
∞
10(m) 5 3 2 1.5 1 0.5 0.1
1 2
Limit1
Limit2
WB
ISO
To Next Page
