Video Settings – Main Assist Functions
407
[SS/Gain Operation]
You can switch the units of shutter speed values and gain (sensitivity)
values.
 []  []  Select [SS/Gain Operation]
[SEC/ISO]
Displays the shutter speed in seconds and the gain in ISO.
[ANGLE/ISO]
Displays the shutter speed in degrees and the gain in ISO.
• The angle can be set in a range between 11° and 357°.
(when [Synchro Scan] is set to [OFF])
[SEC/dB]
Displays the shutter speed in seconds and the gain in dB.
• The setting items for gain are as follows:
– Normal: [AUTO], [0dB] to [42dB]
– When [Extended Gain Setting] is set: [−6dB] to [42dB]
• 0 dB corresponds to either of the following ISO sensitivity values.
– Normal: 100
– When [V-Log]/[REAL TIME LUT] is set in [Photo Style]: 500 (sensor output 60 fps
or lower)/250 (sensor output 61 fps or higher)
– When [Hybrid Log Gamma] is set in [Photo Style]: 250
