Panasonic PT-TX430 - List of Compatible Signals

104 - ENGLISH
List of compatible signals
The following table species the type of signals compatible with the projectors.
f Symbols that indicate formats are as follows.
g V: VIDEO, Y/C
g R: RGB (analog)
g Y: YC
B
C
R
/YP
B
P
R
(analog)
g H: HDMI
Mode
Display resolution
(dots)
Scanning frequency
Dot clock
frequency
(MHz)
Format*
1
PnP *
2
H (kHz) V (Hz)
Computer 1/
Computer 2
HDMI
NTSC/NTSC4.43/
PAL-M/PAL60
720 x 480i 15.7 59.9 -- V -- --
PAL/PAL-N/
SECAM
720 x 576i 15.6 50.0 -- V -- --
480/60i 720 x 480i 15.7 59.9 13.5 R/Y -- --
576/50i 720 x 576i 15.6 50.0 13.5 R/Y -- --
480/60i 720 (1 440) x 480i*
3
15.7 59.9 27.0 H --
l
576/50i 720 (1 440) x 576i*
3
15.6 50.0 27.0 H --
l
480/60p 720 x 483 31.5 59.9 27.0 R/Y/H --
l
576/50p 720 x 576 31.3 50.0 27.0 R/Y/H --
l
720/60p 1 280 x 720 45.0 60.0 74.3 R/Y/H --
l
720/50p 1 280 x 720 37.5 50.0 74.3 R/Y/H --
l
1080/60i 1 920 x 1 080i 33.8 60.0 74.3 R/Y/H --
l
1080/50i 1 920 x 1 080i 28.1 50.0 74.3 R/Y/H --
l
1080/24p 1 920 x 1 080 27.0 24.0 74.3 R/Y/H --
l
1080/24sF 1 920 x 1 080i 27.0 48.0 74.3 R/Y/H -- --
1080/25p 1 920 x 1 080 28.1 25.0 74.3 R/Y/H -- --
1080/30p 1 920 x 1 080 33.8 30.0 74.3 R/Y/H -- --
1080/60p 1 920 x 1 080 67.5 60.0 148.5 R/Y/H --
l
1080/50p 1 920 x 1 080 56.3 50.0 148.5 R/Y/H --
l
640 x 480/60 640 x 480 31.5 59.9 25.2 R/H
l l
640 x 480/67 640 x 480 35.0 66.7 30.2 R/H -- --
640 x 480/73 640 x 480 37.9 72.8 31.5 R/H
l l
640 x 480/75 640 x 480 37.5 75.0 31.5 R/H
l l
640 x 480/85 640 x 480 43.3 85.0 36.0 R/H -- --
800 x 600/56 800 x 600 35.2 56.3 36.0 R/H
l l
800 x 600/60 800 x 600 37.9 60.3 40.0 R/H
l l
800 x 600/72 800 x 600 48.1 72.2 50.0 R/H
l l
800 x 600/75 800 x 600 46.9 75.0 49.5 R/H
l l
800 x 600/85 800 x 600 53.7 85.1 56.3 R/H -- --
832 x 624/75 832 x 624 49.7 74.6 57.3 R/H
l l
1024 x 768/60 1 024 x 768 48.4 60.0 65.0 R/H
l l
1024 x 768/70 1 024 x 768 56.5 70.1 75.0 R/H
l l
1024 x 768/75 1 024 x 768 60.0 75.0 78.8 R/H
l l
1024 x 768/85 1 024 x 768 68.7 85.0 94.5 R/H -- --
1152 x 864/75 1 152 x 864 67.5 75.0 108.0 R/H -- --
1152 x 870/75 1 152 x 870 68.7 75.1 100.0 R/H
l l
1280 x 720/50 1 280 x 720 37.1 49.8 60.5 R/H -- --
1280 x 720/60 1 280 x 720 44.8 59.9 74.5 R/H -- --
1280 x 768/60 1 280 x 768 47.8 59.9 79.5 R/H -- --
1280 x 768/75 1 280 x 768 60.3 74.9 102.3 R/H -- --
1280 x 768/85 1 280 x 768 68.6 84.8 117.5 R/H -- --
1280 x 800/50 1 280 x 800 41.3 50.0 68.0 R/H -- --
Chapter 7 Appendix - Technical Information
