22 - ENGLISH
Attention
f Do not block the ventilation ports (intake and exhaust) of the projector.
WARNING
Keep your hands and other objects away from the air exhaust port.
f Keep your hand and face away.
f Do not insert your nger.
f Keep heat-sensitive articles away.
Heated air from the air exhaust port can cause burns, injury, or deformations.
Note
f The remote control can be used within a distance of about 5 m (16'4-13/16") if pointed directly at the remote control signal
receiver. The remote control can control at angles of up to ± 30 ° vertically and ± 30 ° horizontally, but the effective control
range may be reduced.
f If there are any obstacles between the remote control and the remote control signal receiver, the remote control may not
operate correctly.
f You can operate the projector by reecting the remote control signal on the screen. The operating range may differ due to
the loss of light caused by the properties of the screen.
f When the remote control signal receiver is lit with a uorescent light or other strong light source, the projector may become
inoperative. Set the projector as far from the luminous source as possible.
Projector body
AC IN
4
1
11
1
2
3
1
1
5 9876 10
Side
Side
Front
Rear
Projection direction
1 Adjustable feet
Adjust the projection angle.
2 Projection Lens
3 Remote control signal receiver (front)
4 Air exhaust port
Connect the supplied power cord.
6 Security slot
This security slot is compatible with the Kensington
security cables.
7 Remote control signal receiver (rear)
8 Security chain hook
Attaches a burglar prevention cable, etc.
9 Rear terminals
10 Speaker
11 Air intake port / Air lter cover (x page 93)
The air lter unit is inside.
Chapter 1 Preparation - About your projector
