ENGLISH - 107
r Connecting terminal
<COMPUTER 1 IN>
terminal
1 (High-density D-sub 15 pin female)
RGB signal 0.7 V [p-p] 75 Ω
HD/SYNC TTL high impedance, automatic positive/negative polarity compatible
VD TTL high impedance, automatic positive/negative polarity compatible
(HD/SYNC and VD do not support 3 value SYNC.)
YP
B
P
R
signal Y: 1.0 V [p-p] including synchronization signal, P
B
P
R
: 0.7 V [p-p] 75 Ω
Y/C signal Y: 1.0 V [p-p] C: 0.286 V [p-p] 75 Ω S1 signal compatible
<COMPUTER 2 IN>
terminal
1 (High-density D-sub 15 pin female)
RGB signal 0.7 V [p-p] 75 Ω
HD/SYNC TTL high impedance, automatic positive/negative polarity compatible
VD TTL high impedance, automatic positive/negative polarity compatible
(HD/SYNC and VD do not support 3 value SYNC.)
<MONITOR OUT> terminal
1 (High-density D-sub 15 pin female)
RGB signal 0.7 V [p-p] 75 Ω
HD/SYNC TTL high impedance, positive/negative polarity compatible
VD TTL high impedance, positive/negative polarity compatible
<VIDEO IN> terminal
1 (Pin jack 1.0 V [p-p] 75 Ω)
<HDMI IN> terminal
1 (HDMI 19 pin, HDCP and Deep color compatible)
Audio signals: Linear PCM (Sampling frequency: 48 kHz/44.1 kHz/32 kHz)
<AUDIO IN> terminal
1 (M3 stereo mini jack, 0.5 V [rms], input impedance 22 kΩ and more)
1 (Pin jack x 2 (L-R), 0.5 V [rms], input impedance 22 kΩ and more)
<VARIABLE AUDIO OUT>
terminal
1 (M3 stereo mini jack, stereo monitor output compatible,
0 V [rms] to 2.0 V [rms] variable, output impedance 2.2 kΩ and less)
<USB A (VIEWER/
WIRELESS)> terminal
USB connector (type A x 1, output DC 5 V, 500 mA maximum)
Memory Viewer / Wireless module (Model No.: ET-WML100) compatible
<USB B (DISPLAY)>
terminal
USB connector (type B x 1), only for USB Display
<SERIAL IN> terminal
1 (D-sub 9 pin, RS-232C compliant, for computer control use)
<LAN> terminal
1 (for RJ-45 network connection, PJLink compatible, 10Base-T/100Base-TX)
r Wireless LAN
To use the wireless LAN function with the projector, it is necessary to attach the optional Wireless Module (Model No.:
ET-WML100).
Compliance standards
IEEE802.11b/g/n
Transmission method
DSSS, OFDM
Frequency range
(Channel)
2 412 MHz to 2 462 MHz (1 to 11 ch)
Transmission speed
(Standard value)
IEEE802.11b Maximum 11 Mbps
IEEE802.11g Maximum 54 Mbps
IEEE802.11n Maximum 150 Mbps
Encryption method
WPA2-PSK(AES)
Chapter 7 Appendix - Specications
