Panasonic SA-MAX500LMK - D-Amp P.C.B.

18.1.9. D-Amp P.C.B.
REF NO.
MODE 1234567891011121314151617181920
POWER ON 2.5 0 0 37 0 -34.1 -28.5 37.3 8.9 0 -37.3 -27.2 -37.3 0 8.9 37.3 -37.1 -37.1 0 37
STANDBY 2.5 0 0 37 0 -34.1 -28.5 37.3 8.9 0 -37.3 -27.2 -37.3 0 8.9 37.3 -37.1 -37.1 0 37
REF NO.
MODE 21 22 23
POWER ON 0 0 5.0
STANDBY 0 0 5.0
REF NO.
MODE 1234567891011121314151617181920
POWER ON 2.5 0 0 37 0 -34.1 -28.6 37.3 8.9 0 -37.4 -27.2 -37.4 0 8.8 37.3 -37.1 -37.1 0 37
STANDBY 2.5 0 0 37 0 -34.1 -28.6 37.3 8.9 0 -37.4 -27.2 -37.4 0 8.8 37.3 -37.1 -37.1 0 37
REF NO.
MODE 21 22 23
POWER ON 0 0 5
STANDBY 0 0 5
REF NO.
MODE 1234567891011121314151617181920
POWER ON 2.5 0 0 37 0 -34.1 -28.6 37.3 8.8 -0.2 -37.3 -27.3 -37.4 -0.3 8.8 37.3 -37.3 -37.2 0 37
STANDBY 2.5 0 0 37 0 -34.1 -28.6 37.3 8.8 -0.2 -37.3 -27.3 -37.4 -0.3 8.8 37.3 -37.3 -37.2 0 37
REF NO.
MODE 21 22 23
POWER ON 0 0 5
STANDBY 0 0 5
REF NO.
MODE 1234567891011121314151617181920
POWER ON 2.5 0 0 37 0 -34.1 -28.5 37.3 8.9 0 -37.3 -27.2 -37.3 0 8.9 37.3 -37.1 -37.1 0 37
STANDBY 2.5 0 0 37 0 -34.1 -28.5 37.3 8.9 0 -37.3 -27.2 -37.3 0 8.9 37.3 -37.1 -37.1 0 37
REF NO.
MODE 21 22 23
POWER ON 0 0 5
STANDBY 0 0 5
REF NO.
MODE 1234567891011121314
POWER ON 0 1.8 5 0 2.6 2.6 0 0 5.4 5.4 0 0 5.4 5.4
STANDBY 0 1.8 5 0 2.6 2.6 0 0 5.4 5.4 0 0 5.4 5.4
REF NO.
MODE E C B E C B E C B E C B
POWER ON 0 3.3 0 0 3.3 0 0 5.0 0 0 0 0.7
STANDBY 0 3.3 0 0 3.3 0 0 5.0 0 0 0 0.7
Q5601 Q5604
IC5400
IC5400
SA-MAX500 D-AMP P.C.B.
IC5500
IC5000
IC5000
IC5200
IC5200
IC5300
IC5300
Q5101 Q5102
