Panasonic SA-MAX8000 - Page 92

92
IC7001 VUEALLPT087 IC 1 (E.S.D)
JIGS&AD
J
IC8001 C0DBGYY00911 IC 1 (E.S.D)
IC8002 C0DBZYY00716 IC 1 (E.S.D)
IC8003 C0DBGYY03909 IC 1 (E.S.D)
IC8004 C0DBAYY01997 IC 1 (E.S.D)
IC8005 C0DBAYY01996 IC 1 (E.S.D)
IC8007 C0DBEYY00146 IC 1 (E.S.D)
IC8008 C0DBZYY00716 IC 1 (E.S.D)
IC8011 C0DBEYY00267 IC 1 (E.S.D)
IC8012 C0DBGYY00969 IC 1 (E.S.D)
IC8501 C0ABBB000342 IC 1 (E.S.D)
IC9001 C0JBAS000401 IC 1 (E.S.D)
TRANSISTORS
Q1001 B1ABCF000176 TRANSISTOR 1 (E.S.D)
Q1101 B1ADNG000003 TRANSISTOR 1 (E.S.D)
Q1103 B1CERR000137 TRANSISTOR 1 (E.S.D)
Q1203 B1ADNG000003 TRANSISTOR 1 (E.S.D)
Q1204 B1CERR000137 TRANSISTOR 1 (E.S.D)
Q1402 B1ACKD000006 TRANSISTOR 1 (E.S.D)
Q1501 B1CERR000137 TRANSISTOR 1 (E.S.D)
Q1502 B1CERR000137 TRANSISTOR 1 (E.S.D)
Q1701 B1HFCDE00002 TRANSISTOR 1 (E.S.D)
Q1702 B1ABCF000176 TRANSISTOR 1 (E.S.D)
Q1702 B1HFCDE00002 TRANSISTOR 1 (E.S.D)
Q1720 B1ADNG000003 TRANSISTOR 1 (E.S.D)
Q1801 B1HFCDE00002 TRANSISTOR 1 (E.S.D)
Q1802 B1ADCE000012 TRANSISTOR 1 (E.S.D)
Q1802 B1HFCDE00002 TRANSISTOR 1 (E.S.D)
Q4001 B1HBCDA00001 TRANSISTOR 1 (E.S.D)
Q4002 B1HBCDA00001 TRANSISTOR 1 (E.S.D)
Q4003 B1ABDF000026 TRANSISTOR 1 (E.S.D)
Q4004 B1ABDF000026 TRANSISTOR 1 (E.S.D)
Q4201 B1CBRK000001 TRANSISTOR 1 (E.S.D)
Q4202 B1CBRK000001 TRANSISTOR 1 (E.S.D)
Q4203 B1CBRK000001 TRANSISTOR 1 (E.S.D)
Q4204 B1CBRK000001 TRANSISTOR 1 (E.S.D)
Q4205 B1CBRK000001 TRANSISTOR 1 (E.S.D)
Q4206 B1CBRK000001 TRANSISTOR 1 (E.S.D)
Q4207 B1CBRK000001 TRANSISTOR 1 (E.S.D)
Q4208 B1CBRK000001 TRANSISTOR 1 (E.S.D)
Q4209 B1HBCDA00001 TRANSISTOR 1 (E.S.D)
Q4501 B1CBRK000001 TRANSISTOR 1 (E.S.D)
Q4502 B1CBRK000001 TRANSISTOR 1 (E.S.D)
Q4503 B1CBRK000001 TRANSISTOR 1 (E.S.D)
Q4504 B1CBRK000001 TRANSISTOR 1 (E.S.D)
Q4505 B1CBRK000001 TRANSISTOR 1 (E.S.D)
Q4506 B1CBRK000001 TRANSISTOR 1 (E.S.D)
Q4507 B1CBRK000001 TRANSISTOR 1 (E.S.D)
Q4508 B1CBRK000001 TRANSISTOR 1 (E.S.D)
Q4509 B1HBCDA00001 TRANSISTOR 1 (E.S.D)
Q4511 B1BACG000048 TRANSISTOR 1 (E.S.D)
Q5001 B1ADCF000001 TRANSISTOR 1 (E.S.D)
Q8001 B1ADGF000010 TRANSISTOR 1 (E.S.D)
Q8501 B1ABCF000231 TRANSISTOR 1 (E.S.D)
Q8502 B1ABCF000231 TRANSISTOR 1 (E.S.D)
Q8503 B1ABCF000231 TRANSISTOR 1 (E.S.D)
Q8504 B1AAJC000019 TRANSISTOR 1 (E.S.D)
Q8505 B1BACG000023 TRANSISTOR 1 (E.S.D)
Q8506 B1ABCF000231 TRANSISTOR 1 (E.S.D)
Q8507 B1ABCF000231 TRANSISTOR 1 (E.S.D)
Q8508 B1ABCF000231 TRANSISTOR 1 (E.S.D)
Q8509 B1ABCF000231 TRANSISTOR 1 (E.S.D)
Q8510 B1ABCF000231 TRANSISTOR 1 (E.S.D)
Q8511 B1ABCF000231 TRANSISTOR 1 (E.S.D)
Q9003 B1ADCE000012 TRANSISTOR 1 (E.S.D)
Q9004 B1ADCE000012 TRANSISTOR 1 (E.S.D)
QR1201 B1GBCFJJ0040 TRANSISTOR 1 (E.S.D)
QR1601 B1GBCFLL0037 TRANSISTOR 1 (E.S.D)
QR1720 B1GBCFLL0037 TRANSISTOR 1 (E.S.D)
QR1802 B1GBCFGN0016 TRANSISTOR 1 (E.S.D)
Safety Ref.
No.
Part No. Part Name &
Description
Qty Remarks
QR4001 B1GBCFJJ0040 TRANSISTOR 1 (E.S.D)
QR4002 B1GDCFJJ0047 TRANSISTOR 1 (E.S.D)
QR4201 B1GBCFJJ0040 TRANSISTOR 1 (E.S.D)
QR4202 B1GBCFJJ0040 TRANSISTOR 1 (E.S.D)
QR4203 B1GDCFJJ0047 TRANSISTOR 1 (E.S.D)
QR4501 B1GBCFJJ0040 TRANSISTOR 1 (E.S.D)
QR4502 B1GDCFNN0032 TRANSISTOR 1 (E.S.D)
QR4901 B1GBCFJJ0040 TRANSISTOR 1 (E.S.D)
QR4902 B1GBCFJJ0040 TRANSISTOR 1 (E.S.D)
QR8001 B1GBCFJJ0040 TRANSISTOR 1 (E.S.D)
QR8003 B1GBCFJJ0040 TRANSISTOR 1 (E.S.D)
QR8004 B1GBCFJN0038 TRANSISTOR 1 (E.S.D)
QR8005 B1GDCFGA0018 TRANSISTOR 1 (E.S.D)
QR8045 B1GBCFNN0038 TRANSISTOR 1 (E.S.D)
QR9002 B1GBCFGN0016 TRANSISTOR 1 (E.S.D)
QR9003 B1GBCFGN0016 TRANSISTOR 1 (E.S.D)
DIODES
D1001 B0FBCR000021 DIODE 1 (E.S.D)
D1101 B0JCPD000039 DIODE 1 (E.S.D)
D1104 B0FABR000025 DIODE 1 (E.S.D)
D1105 B0ECNR000003 DIODE 1 (E.S.D)
D1206 DZ2J051M0L DIODE 1 (E.S.D)
D1207 B0JCPD000039 DIODE 1 (E.S.D)
D1208 B0FABR000025 DIODE 1 (E.S.D)
D1402 B0EDHS000002 DIODE 1 (E.S.D)
D1403 B0HAMP000094 DIODE 1 (E.S.D)
D1404 B0EAMM000057 DIODE 1 (E.S.D)
D1405 B0EAMM000057 DIODE 1 (E.S.D)
D1406 B0ECET000006 DIODE 1 (E.S.D)
D1500 B3AAA0001129 DIODE 1 (E.S.D)
D1501 B3AAA0001129 DIODE 1 (E.S.D)
D1502 B3AAA0001129 DIODE 1 (E.S.D)
D1502 DZ2J120M0L DIODE 1 (E.S.D)
D1503 B0HAMP000094 DIODE 1 (E.S.D)
D1503 B3AAA0001129 DIODE 1 (E.S.D)
D1504 B0JCPD000039 DIODE 1 (E.S.D)
D1504 B3AAA0001129 DIODE 1 (E.S.D)
D1505 B0JCPD000039 DIODE 1 (E.S.D)
D1505 B3AAA0001129 DIODE 1 (E.S.D)
D1506 B0EAMR000018 DIODE 1 (E.S.D)
D1506 B3AAA0001129 DIODE 1 (E.S.D)
D1507 B0EAMM000057 DIODE 1 (E.S.D)
D1507 DA2J10100L DIODE 1 (E.S.D)
D1508 B0EAMM000057 DIODE 1 (E.S.D)
D1508 B3AAA0001129 DIODE 1 (E.S.D)
D1509 B0EAMM000057 DIODE 1 (E.S.D)
D1510 B0EAMM000057 DIODE 1 (E.S.D)
D1511 B3AAA0001129 DIODE 1 (E.S.D)
D1512 DA2J10100L DIODE 1 (E.S.D)
D1513 DA2J10100L DIODE 1 (E.S.D)
D1514 B0JCGD000016 DIODE 1 (E.S.D)
D1515 DA2J10100L DIODE 1 (E.S.D)
D1516 DA2J10100L DIODE 1 (E.S.D)
D1517 DA2J10100L DIODE 1 (E.S.D)
D1518 DA2J10100L DIODE 1 (E.S.D)
D1522 DA2J10100L DIODE 1 (E.S.D)
D1600 B3AEA0000158 DIODE 1 (E.S.D)
D1601 B0EAMM000057 DIODE 1 (E.S.D)
D1601 B3AEA0000158 DIODE 1 (E.S.D)
D1701 B0ADDH000009 DIODE 1 (E.S.D)
D1701 DZ2J150M0L DIODE 1 (E.S.D)
D1702 B0ADDH000009 DIODE 1 (E.S.D)
D1702 B0JBSG000053 DIODE 1 (E.S.D)
D1703 B0JBSL000029 DIODE 1 (E.S.D)
D1704 B0JBSL000029 DIODE 1 (E.S.D)
D1705 B0JBSL000029 DIODE 1 (E.S.D)
D1706 B0JBSL000029 DIODE 1 (E.S.D)
D1801 B0ADDH000009 DIODE 1 (E.S.D)
D1802 B0ADDH000009 DIODE 1 (E.S.D)
D1950 B3AZB0000101 DIODE 1 (E.S.D)
D1951 B3AZB0000101 DIODE 1 (E.S.D)
Safety Ref.
No.
Part No. Part Name &
Description
Qty Remarks
