D1952 DA2J10100L DIODE 1 (E.S.D)
D1953 DA2J10100L DIODE 1 (E.S.D)
D1954 DA2J10100L DIODE 1 (E.S.D)
D1955 DA2J10100L DIODE 1 (E.S.D)
D1980 B3AZB0000101 DIODE 1 (E.S.D)
D1981 B3AZB0000101 DIODE 1 (E.S.D)
D1982 DA2J10100L DIODE 1 (E.S.D)
D1983 DA2J10100L DIODE 1 (E.S.D)
D1984 DA2J10100L DIODE 1 (E.S.D)
D1985 DA2J10100L DIODE 1 (E.S.D)
D4201 B0ACGM000002 DIODE 1 (E.S.D)
D4202 B0ACGM000002 DIODE 1 (E.S.D)
D4203 B0ACGM000002 DIODE 1 (E.S.D)
D4204 B0ACGM000002 DIODE 1 (E.S.D)
D4205 B0ACGM000002 DIODE 1 (E.S.D)
D4206 B0ACGM000002 DIODE 1 (E.S.D)
D4207 B0ACGM000002 DIODE 1 (E.S.D)
D4208 B0ACGM000002 DIODE 1 (E.S.D)
D4209 DA2J10100L DIODE 1 (E.S.D)
D4210 B0HCMM000024 DIODE 1 (E.S.D)
D4211 B0HCMM000024 DIODE 1 (E.S.D)
D4212 B0HCMM000024 DIODE 1 (E.S.D)
D4213 B0HCMM000024 DIODE 1 (E.S.D)
D4214 B0HCMM000024 DIODE 1 (E.S.D)
D4215 B0HCMM000024 DIODE 1 (E.S.D)
D4216 B0HCMM000024 DIODE 1 (E.S.D)
D4217 B0HCMM000024 DIODE 1 (E.S.D)
D4218 DA2J10100L DIODE 1 (E.S.D)
D4219 DA2J10100L DIODE 1 (E.S.D)
D4501 B0ACGM000002 DIODE 1 (E.S.D)
D4502 B0ACGM000002 DIODE 1 (E.S.D)
D4503 B0ACGM000002 DIODE 1 (E.S.D)
D4504 B0ACGM000002 DIODE 1 (E.S.D)
D4505 B0ACGM000002 DIODE 1 (E.S.D)
D4506 B0ACGM000002 DIODE 1 (E.S.D)
D4507 B0ACGM000002 DIODE 1 (E.S.D)
D4508 B0ACGM000002 DIODE 1 (E.S.D)
D4509 DA2J10100L DIODE 1 (E.S.D)
D4510 B0HCMM000024 DIODE 1 (E.S.D)
D4511 B0HCMM000024 DIODE 1 (E.S.D)
D4512 B0HCMM000024 DIODE 1 (E.S.D)
D4513 B0HCMM000024 DIODE 1 (E.S.D)
D4514 B0HCMM000024 DIODE 1 (E.S.D)
D4515 B0HCMM000024 DIODE 1 (E.S.D)
D4516 B0HCMM000024 DIODE 1 (E.S.D)
D4517 B0HCMM000024 DIODE 1 (E.S.D)
D4518 DA2J10100L DIODE 1 (E.S.D)
D4519 DZ2J051M0L DIODE 1 (E.S.D)
D4520 DZ2J110M0L DIODE 1 (E.S.D)
D4521 DZ2J150M0L DIODE 1 (E.S.D)
D5001 B0JCAE000001 DIODE 1 (E.S.D)
D8001 DA2J10100L DIODE 1 (E.S.D)
D8003 DA2J10100L DIODE 1 (E.S.D)
D8004 DA2J10100L DIODE 1 (E.S.D)
D8005 DZ2J062M0L DIODE 1 (E.S.D)
D8006 DZ2J062M0L DIODE 1 (E.S.D)
D8008 DA2J10100L DIODE 1 (E.S.D)
D8011 DA2J10100L DIODE 1 (E.S.D)
D8012 DZ2J130M0L DIODE 1 (E.S.D)
D8013 B0JCGD000016 DIODE 1 (E.S.D)
D8040 B0ADDH000009 DIODE 1 (E.S.D)
D8501 DA2J10100L DIODE 1 (E.S.D)
D8502 DA2J10100L DIODE 1 (E.S.D)
D8503 DA2J10100L DIODE 1 (E.S.D)
D9000 B3AAA0000487 DIODE 1 (E.S.D)
D9001 B3AAA0000487 DIODE 1 (E.S.D)
SURGE ABSORBER
DZ1001 D4EAY511A127 SURGE ABSORBER 1 (E.S.D)
VARIABLE RESIS-
TORS
Safety Ref.
No.
Part No. Part Name &
Description
Qty Remarks
VR1401 EVUE27FK2B53 MIC JOG 1
VR1600 EVEKE2F3024B VOLUME JOG 1
VR1930 EVEKE2F3024B ILLUMINATION JOG 1
VR1960 EVEKE2F3024B VOLUME JOG 1
REMOTE SENSOR
IR1730 B3RAB0000109 REMOTE SENSOR 1
ESD SUPRESSOR
VA7001 EZAEG2A50AX ESD SUPRESSOR 1
LCD DISPLAYS
DP1700 A2BB00000186 LCD DISPLAY 1
DP1800 A2BB00000186 LCD DISPLAY 1
PHOTO COUPLERS
Q1403 B3PBA0000579 PHOTO COUPLER 1 (E.S.D)
Q1405 B3PBA0000579 PHOTO COUPLER 1 (E.S.D)
Q1404 B3PBA0000579 PHOTO COUPLER 1 (E.S.D)
Q1505 B3PBA0000579 PHOTO COUPLER 1 (E.S.D)
FUSE
F1001 K5D103BNA005 FUSE 1
F1401 K5G501YA0081 FUSE 1
F1501 K5G502Y00006 FUSE 1
SWITCHES
S1500 EVQ21405RJ SW POWER 1
S1501 EVQ21405RJ SW MANUAL EQ 1
S1502 EVQ21405RJ SW LATIN /PRE-
SET EQ
1
S1503 EVQ21405RJ SW D.BASS/-SUB-
WOOFER
1
S1504 EVQ21405RJ SW MEMORY 3 1
S1505 EVQ21405RJ SW MEMORY 2 1
S1506 EVQ21405RJ SW MEMORY 1 1
S1507 EVQ21405RJ SW MEMORY 5 1
S1508 EVQ21405RJ SW MEMORY 4 1
S1509 EVQ21405RJ SW MEMORY 6 1
S1510 EVQ21405RJ SW DJ EFFECT 1
S1511 EVQ21405RJ SW DJ SAMPLER 1
S1512 EVQ21405RJ SW DJ JUKEBOX 1
S1650 EVQ21405RJ SW OPEN/CLOSE 1
S1651 EVQ21405RJ SW USB REC 1
S1652 EVQ21405RJ SW MEMORY REC 1
S1653 EVQ21405RJ SW REW 1
S1654 EVQ21405RJ SW FF 1
S1655 EVQ21405RJ SW ALBUM/TRACK 1
S1656 EVQ21405RJ SW STOP/TUNE
MODE
1
S1657 EVQ21405RJ SW BLUETOOTH/
MEMORY
1
S1658 EVQ21405RJ SW PLAYBACK 1
S1659 EVQ21405RJ SW USB/CD 1
S1660 EVQ21405RJ SW RADIO/EXT-IN 1
S7201 K0L1BA000158 SW RESET 1
CONNECTORS
CN1401 K1KA09BA0061 9P CONNECTOR 1
CN1851 K1KA13BA0062 13P CONNECTOR 1
CN1852 K1KA02BA0125 2P CONNECTOR 1
CN1853 K1KA10BA0056 10P CONNECTOR 1
CN1854 K1KA03BA0061 3P CONNECTOR 1
CN7001 K1MY05BA0539 5P CONNECTOR 1
CN7002 K1MN10B00016 10P CONNECTOR 1
