Page 3-2 HandiLaz Mini Operator’s Manual
Chapter 3: MEASURE MODE Settings
4
Press the
ENTER
key.
The REPEAT measure mode setup screen will open.
NOTE:
The
NO
in the lower-right corner indicates that the setup is not
complete and the screen is ready to be edited. If setup is complete, set
NO
to
OK
.
REPEAT Sample Parameters
The parameters displayed when the REPEAT measure mode is opened are those
that were saved when the REPEAT mode was last run. The REPEAT mode can
be run as it is, without changing any sample parameters.
To edit the setup screen:
1
Press the
ENTER
key.
Pressing
ENTER
moves the cursor in a loop through each field that can be edited.
2
At the field to be changed, press the up or down keys.
The field setting will loop through its range of allowable settings.
3
When the field is set correctly, press the
ENTER
key again to move to the next
field.
To close the edit function and run the sample:
1
Use the
ENTER
key to navigate to NO.
2
Use the up or down key to toggle the NO to OK.
3
Press the
START/STOP
key.
The SAMPLING display will appear.
Taking REPEAT Samples
From the SAMPLING display, press the
ENTER
key. During the initial delay,
the HandiLaz Mini displays WAIT. When READY is displayed, press
START/
STOP
to begin sampling. Alternatively, the unit can be set to AUTOSTART
sampling. See “Setting AUTOSTART (AUTOST)” on page 5-6.
REPEAT 0.3/0.5/5.0µm
LOC.023 STR:N BEEP:N
SAMPLE 00:15 3TIMES
INT 00:00:30 NO
SAMPLING
SAMPLE TIME 00:00:45
TOTAL TIME 00:01:15
FREE REC.:09500 OK
