Particle Measuring Systems HandiLaz Mini User Manual

Using the Retrieval Software
HandiLaz Data Retrieval Software, Installing and Running Page E-6
Start the Retrieval Software
1 Click on the Windows Start button at the bottom left of the monitor.
2 Click on Programs > PMS-Handheld LPC PC-LINK. The program will start,
and the Retrieval Software dialog box will appear on the monitor.
Start HandiLaz Mini and Verify or Set its Address
1 Press the POWER key to start the HandiLaz Mini. The <MENU> display will
appear on the HandiLaz Mini.
2 From the MENU display use the up ▲ or down ▼ key to navigate to
OPTIONS.
3 Press the ENTER button. The <OPTIONS> menu will open.
4 Navigate to ADDRESS.
5 If the address has already been set, record it and proceed to the next set of
instructions.
If the address has not been set, use the up ▲ or down ▼ key to set the two-digit
address field to a number from 00 to 31.
6 Record the address and proceed to the next set of instructions.
Set HandiLaz Mini to Upload Data
1 From the MENU display use the up ▲ or down ▼ key to navigate to
DATA PROCESSING.
Figure E-7: Connection by means of USB Cable
