23
Executive
Protocol ?
Price Holding
mode ?
Send prices
to V.M. FAS ?
MDB-ICP
Protocol ?
BDV-Master
Protocol ?
External IrDA
interface ?
Use Selection No.
for Audit ?
1st Selection
is number… ? 0
Send price to
VMC ?
Protocol:
N=DDCMP Y=DEX-UCS
Fn00 – General parameters
All the parameters in this function must be set (a parameter being omitted might cause a malfunctioning).
Select data collection protocol (Audit)
N DDCMP. Protocol DDCMP is used to transfer Audit data.
Y DEX-UCS. Protocol DEX-UCS is used to transfer Audit data.
N No external IrDA has been connected.
Y External IrDA connected.
Select “Y” even if a Paytec key reader with IrDA is connected.
When selecting “Y”, the IrDA on EAGLE faceplate is inhibited.
N Protocol inhibited (next).
Y Executive protocol enabled.
Y N Executive standard (prices are controlled by VM).
Y Executive Price-Holding (prices are controlled by EAGLE).
Enter prices in Fn04, then match each price to a selection number
in Fn17 (up to 100 prices - see Fn19). The equivalent Price Holding
mode must be set on the VM.
Only valid in Price Holding mode with 100 prices with FAS
N Inhibited.
Y The VM FAS is going to read the price lists with CASH and with
CASHLESS price transmitted by the changegiver. This option is only
valid in Price Holding mode with 100 prices (see Fn19).
Only valid in Price Holding mode.
N Standard.
Y The price is transmitted and displayed on the VM whenever pressing
a selection button (even if no money has been inserted).
N Protocol inhibited (next).
Y Protocol MDB Slave enabled (EAGLE works as a peripheral MDB
unit).
Serial cable MDB is necessary.
Set according to how vends are controlled by the VM.
N Vends are memorized by price.
Y Vends are memorized by selection number.
Warning! In MDB protocol, the 1
st
selection number sent by the VM is 0
(corresponding to no.1 in Audit list).
Set the 1
st
number corresponding to the number transmitted by the VM
(with MDB protocol).
N Protocol inhibited.
Y Protocol BDV001 Master enabled.
