30
Fn03 – Coin parameters
Parameters can be read in Fn03 for each coin (up to 30 coin channels).
Some parameters can also be modified.
Select a channel, then press
to scroll down the list of parameters.
Press ESC to exit a function.
Adjust coin parameters with the utmost care; an incorrect setting might prejudice coin discrimination level.
Enter the number of a coin channel, then press
to confirm.
N The tube selected contains other coins than Euro.
Y The tube selected contains Euro coins.
Euro coins are accepted by “currency description = 978” in Fn00.
Coin value (65500 max.)
Enter coin value, then press
to confirm.
This value must be equal to the USF in Fn01 (or a multiple of it).
N The 1
st
coin parameter is displayed.
Y Scroll down the list of coin options.
N The coin is accepted.
Y The coin is NOT accepted (channel inhibited).
DO NOT MODIFY THIS PARAMETER
This channel is protected against writing (only-read parameters).
Such channel can be inhibited but not modified.
N The coin is always accepted.
Y Black Coin channel (the coin is NOT accepted).
Standard setting : “N”
Coin destination
N The coin does not fall in tube 1.
Y The coin falls in tube 1 (tube A).
Do the same for each of the six tubes.
→
If you leave N for all the tubes, the coins fall in the cashbox.
→
When the destination tube is full, the coin falls in the cashbox.
→
A coin can be routed to different tubes (check compatibility in
diameter).
Select
coin No. 1
Coin No. 1
Euro ?
1^ Coin
value:
List coin
options 1 ?
inhibited ?
Coin Protected Y
Black Coin ?
Tube 1 ?
Tube 2 ?
Tube … ?
Tube 6 ?
