Fig.18
Fig.19
Paytec Configurator
PC application
Paytec Configurator is a Windows
®
PC application designed to manage the configuration of EAGLE changegiver
via USB serial connection to a PC (fig.18).
The application also allows programming coins in free channels from a PCs and running diagnostics on coin
acceptance, with the possibility of saving a test report for a later analysis of data.
Minimum requirements for Configurator: PC Windows
®
, USB serial port.
Use the Paytec USB interface cable mod.UIC1 for connection to the system.
Paytec Configurator and its user guide can be downloaded from www.paytec.eu.
You can connect Eagle and the PC in P6000 emulator mode. All the functions are controlled with PC keyboard
and displayed on PC screen (see Fig.19).
P6000
E
mulat
or
Window displayed
