Fn08 – Coins programming
Up to 30 coin channels can be programmed on EAGLE. Free channels can be configured while the coin channels
configured by default are protected against writing.
After starting the system, wait 1 minute before programming coins.
Programming coin channels with a palmtop P6000 (or with a Smartphone Android
™
with the APP PayTools)
Enter Fn08, set the parameters required, then insert the coins you wish to configure.
Programming coin channels with a PC
Coins can be programmed with the software “Paytec Configurator” rev. 6.00 or later (compatible with Windows
®
XP/7). Coins must be inserted in the system anyway, even if they are programmed with a PC application.
It is necessary to use a USB cable (accessory).
When selecting a coin channel programmed by default, the message “Error Coin Protected” is displayed (select
another coin channel !).
Programming coins with P6000
Enter the number of the channel you wish to configure and press
.
When the message "Error Coin Protected” is displayed, try with another
channel.
EUR models: channels 1 to 8 are protected by default.
No. coins that have to be inserted when programming that coin type.
Enter a number (4 to 99), then press
to confirm.
No. passages recommended = 10
Enter the "Delta" increase calculated by the software (0 to 15), then press
to confirm.
It is preferable to start with low values (3 or 4), then make adjustments
depending on coin acceptance tests.
After coin channels have been configured, delta values can be
modified in Fn03.
Options to program fake coins/tokens that won’t be accepted.
A coin/token recognized as a Black Coin will be ejected as a fake.
N Valid coin/token.
Y Coin/token type Black Coin.
Contact Paytec Customer Service for more info about Black Coin channel.
Insert coins slowly one by one. Coins should fall into the recovery channel.
The menu of the P6000 goes back to the opening line of Fn08 after the last
coin has been inserted
LCD Notice: the number of coins that have been inserted so far and the overall
number of coins that must be inserted is displayed on EAGLE LCD.
After all coins have been inserted, you have to adjust their parameters in Fn03.
