Paytec Eagle - Page 25

25
Enable single
bill ?
Enable all bills
high ?
Enable single
bill high ?
Coges LMB?
Coges Eureka or
Edue F30 ?
Smiley NV4-5 or
Edue Primo V10 ?
PAYTEC Parallel
CBV IVO/B2 ?
CBV125
J01/A25/A2A ?
PAYTEC Pulse
ICT–A7 JCM-DBV ?
Binary mode ?
The parameters here below enable you to select some models in PARALLEL mode (see Fn05).
N Next.
Y Coges LMB connected.
N Next.
Y Coges Eureka connected.
N Next.
Y Smiley NV4 connected in parallel mode (this validator type enables
users to inhibit single bills).
N Smiley with parallel outputs.
Y Smiley with binary outputs (no data-valid).
N Next.
Y PAYTEC bill validator in parallel mode (100 msecs.timed outputs).
N Next.
Y CBV/125 in parallel mode (100 msecs. timed outputs).
N Next.
Y One of the following bill validators is connected in pulse mode:
- PAYTEC Pulse model;
- JCM DBV301;
- ICT A7.
N All the bills are accepted.
Y Every bill channel can be dynamically enabled/inhibited (for compatible
validators only). All those bills are inhibited whose value –added to the
credit displayed– is higher than the max. credit programmed.
N Signal “enable” low (0.4V/50mA max.)
Y Signal “enable” high (PVcc/50mA/Pull-Up 1K).
N Signal “enable” low (0.4V/50mA max.)
Y Signal “enable” high (PVcc/50mA/Pull-Up 10K).
Possible configurations for bill validators
PAYTEC
Parallel mode
PAYTEC
Pulse mode
Bills always enabled ?
N N
Enable single bill ?
N N
Enable all bills high ?
N N
Enable single bill high ?
N N
Notice: Payment Technologies S.r.l. is NOT responsible if a setting is different from the setting indicated.
