83
Test Ejectors:
N
Testing…
M1 M2 M3 ABCDEF
- - - ------
Motor F OK
Ejectors 111110
Motor F OK
Ejectors 111111
Y
Diameter
Coefficient **
Thickness
Coefficient **
Alloy
Coefficient **
Advanced servicing function (for authorized staff only).
N Ejectors are not tested (next).
Y The six ejectors are automatically tested. Press (P6000) to start the
test. Single ejectors will be automatically activated in a sequence.
…. ejectors are being tested…
After ejectors have been tested, the result is displayed for each ejector:
“-“ = OK
“E” = an error has been detected.
M1 motor ejectors A-D.
M2 motor ejectors B-E.
M3 motor ejectors C-F.
ABCDEF pullers for each tube.
Should an error be detected, you should test that ejector (see next
parameter).
While this message is displayed each ejector can be tested manually. Press
a button (EAGLE keypad) to make the corresponding puller move
completely forward, then press the same button the bring the puller back to
its correct position. The logic levels of ejector sensors are displayed on
P6000, depending on the position of their pullers.
Testing ejector ‘F’ (simulating a coin being ejected).
When pressing F, the puller moves to “coin eject” position: the logic level
switches from 1 to 0 ….
…. when pressing ‘F’ again (or another button) the puller moves to its
standby position: the logic level switches from 0 to 1…
Should problems arise when testing the ejectors, please contact Paytec Customer Service.
Press
on P6000 to exit testing function.
After you have left the menu ‘test ejectors’, the coin separator is automatically reset.
Only-read parameter (for staff of Payment Technologies S.r.l. only).
Only-read parameter (for staff of Payment Technologies S.r.l. only).
Only-read parameter (for staff of Payment Technologies S.r.l. only).
