13 Document Number: PD196-103 Rev 1
Installation
LOCATION GUIDELINES
The model PDI-P20LCDC Hospital Grade LCD TV is a specialized LCD television. This TV is
intended for entertainment and educational purposes for use in a hospital, a nursing home, a
medical-care center, or a similar health-care facility in which installation is limited to a non-
hazardous area in accordance with the National Electrical Code, ANSI/NFPA 70. The PDI-
P20LCDC is designed for mounting to PDI manufactured mounts. Installation of the TV on any
other mount is not recommended.
WARNING: The TV’s VESA mounting
holes are designed for M4 metric screws
only. Use of a non-PDI approved mount or
SAE hardware could result in a condition
where the TV could unexpectedly fall and
cause injury or death.
The PDI-P20LCDC TV mounts at the foot of a patient’s bed. Select a location that is
near an AC wall outlet and that does not expose the TV to bright room lights or sunlight if
possible. The LCD TV also requires connection of both CATV cable signal and across-
room wiring for the pillow speaker.
OSHPD (State of California Only)
The combined weight of the PDI-P20LCDC TV and PDI Standard Wall Mount totals less than
20 pounds. At the time of this writing, the involvement of a written, submitted, reviewed, and
approved plan by OSHPD is not required to install the PDI-P20LCDC TV in the state of
California.
CABLE SYSTEM GROUNDING
The coax cable system connected to the PDI-P20LCDC TV should be grounded in accordance
with the National Electrical Code, ANSI/NFPA 70. The code provides guidelines for proper
grounding and, in particular, specifies that the cable ground shall be connected to the
grounding system of the building, as close to the point of the cable entry as practical.
