76700 -41/94-
13-3. Writing FW
* In this step, the connection of each circuit board and the output of
a video signal are confirmed by writing FW.
* When the FW writing (for service) is done, all settings are initialized.
[Caution 1] Writing the FW is necessary whenever 0-T100
is replaced.
[Caution 2] Always use the latest version FW whenever writing the FW.
(1) Surely insert the SD card (FW for service) into the 0-T100.
(2) Connect the video cable and AC adapter to the camera.
(3) The version of CPU/DSP will be displayed on the
TV monitor
[NOTE] If you want to cancel writing firmware,
disconnect AC adapter and eject the SD card.
(4) Remove the SD card when the message as
>>> EJECT SD CARD <<< is displayed, and then
the loading of firmware will be started.
It takes approx 90 sec. until the loading is finished. (UPDATING…)
[CAUTION] Do not turn OFF the camera while loading firmware.
(5) When POWER OFF is displayed, disconnect the AC adapter
from the camera. (Leave the Video cable)
13.4 Data initialization
*If excute this initialization, all EEPROM data will be initialized (Cleared)
[Caution] When replacing 0-T100, you must excute this initialization.
In other case, s not necessary to excute Data initialization.
(1) Install SD card (For data initialization) to the camera.
(2) Connect the ACadaptor. (Initialization will be started.
It takes approx 20 sec.)
[Caution] Do not t F the power
(3) When monitor display is turn off, (“WAIT…” “COMPLETE…” )
disconnect the AC adapter.
13-5. Setting test mode
*With this setting, camera can operate even without SD card cover.
(1) Insert SD card for Test mode ON to the camera.
(2) Connect AC adaptor to the camera. (LCD will be displayed moment)
(3) Disaplay the LCD monitor then disconnect the AC adapter.
(4) Remove SD card from the camera.
(5) When connect AC adaptor again, LCD monitor will be displayed.
Also when press shutter button half way, display will be appeared on the LCD
DETECTED BOTH F/W FILE
NOW LOADING
DETECTED FIRMWARE FILE
COMPLETE LOADING
------- CPU --------
CURRENT VER.1.00.00.00
UPDATE VER.1.00.00.10
======= DSP ========
CURRENT VER.1.00.00.00
UPDATE VER.1.00.00.10
>>> EJECT SD CARD <<<
PENTAX K100D
UPDATING DSP FIRMWARE
SECTOR** >> PROGRAM
_____________
NEVER POWER OFF
PENTAX K100D
UPDATING DSP FIRMWARE
**** COMPLETE ****
VERSION 1.00.00.10
POWER OFF
WAIT
COMPLETE
VERIFY:****
