Pentax K100D - Main Body Assembly Procedures

76700 -31/94-
3. Assembly procedure of main body
1. Main body + Battery chamber
(1) A13 Battery chamber and relating parts.
[Caution]Check the position of lead wires and battery seal.
(2) Attach Main body to the A13.
(3) TY-CNL-D1.7x4.0 x 2
2. 0-E000 (Shutter block)
(1) 0-E000 - Check there is no dust and scratch.
(2) A70- x3 (sholder screw)
*After install, 0-E000 has a little movement.
②
①
A20
A12
A12
Gray
Blac
k
TY-CNL-D
1.7x3.5(x3)
A16
TY-CNS2.0x4.5
Red
White
N300
A13
TY-CNL-B
1.4x3.0
Yellow
Blac
k
T10
Su
p
e
r
-X
(
Black, x3
)
A14
TY-CNL-D1.7x3.5
Red
(
3
)
(2)
