Pentax K100D User Manual

76700 -50/94-
(9)
18.0-A301 (Top cover)
*Befor installing 0-A301, confirm installed condition for parts.
*There is no bent for Main SW contact and confirm that the contact is the same hight.
(1) Apply G151 to land of Main SW contact.
(2) Confirm that the land for Main SW on T200 is not shorted by solder.
(3) Put top cover to body.
(4) Solder 3 lead wires. (Pink, Purple, Black)
(5) Pop-up Flash for installing screw.
(6) Arrange 3 lead wires between body and top cover, then attach
top cover to the body without pinching lead wires.
(7) Connect T51 Flex + Fold Excess Flex under Top cover
(8) A73 (TY screw x2, 4.5mm)
(9) A73 (TY screw)
(10) A74 (TY screw x2, 5.5mm)
(11)TY-CNL-D1.7x8.0 (Battery chamber)
(8)
(7)
(10)
(1)
G151
(5)
(2) Main SW
Land
(4) Pink
Purple
Black
(A330)
(3)

Pentax K100D Specifications

General

Megapixel	6.1 MP
Sensor type	CCD
Interface	USB 2.0
Color depth	8 bit
Digital SLR	Yes
Video capability	No
Camera shutter speed	1/4000 - 30 s
Focus	TTL
Auto focusing (AF) modes	centre weighted auto focus, continuous auto focus, selective auto focus
Light metering	Centre-weighted, Spot
ISO sensitivity	200, 400, 800, 1600, 3200, Auto
Light exposure modes	aperture priority AE, auto, shutter priority AE
Compatible memory cards	sd
Display diagonal	2.5 \
Display resolution (numeric)	210000 pixels
Magnification	0.85X x
I/O ports	AV - NTSC/PAL
USB version	2.0
Product color	Black
Battery type	AA
Number of batteries supported	4
Flash modes	auto, Flash off, Red-eye reduction
Scene modes	beach, Candlelight, Children, Close-up (macro), Documents, Museum, Night, Night portrait, Portrait, Sunset, Landscape (scenery)
Photo effects	black&white, Sepia
White balance	Cloudy, daylight, flash, Fluorescent, manual, Shade, Tungsten
Camera shutter type	Electronic

Weight and Dimensions

Depth	70 mm
Width	129.5 mm
Height	92.5 mm
Weight	570 g
