Pentax K100D User Manual

76700 -24/94-
6. 【ADJ】Positioning 1
st
and 2
nd
Mirror
[Required equipment] 1
st
mirror angle (45°) adjusting jig, Mirror angle adjusting jig for 27830,
Mirror positioning scope.
＊Adjustment is performed by turning B58 (2 pcs). The Y-axis (the vertical direction) is adjusted
to a 0 target.
＊Front housing must set mirror down position.
① Positioning 1 st mirror : Put the 1
st
mirror angle (45°) adjusting jig on the camera,
and then adjust the mirror seat so that the adjusting jig touches the mirror without gap.
Tolerance ---- X-axis : ±15’
Y-axis : ±10’
② Positioning 2
nd
mirror : Attach the mirror positioning scope and the
2
nd
mirror angle adjusting jig to the camea, and then adjust the
mirror angle while looking through the eyepiece lens.
Tolerance ---- X-axis : ±0.3mm
Y-axis : ±0.1mm
(Refer to below tolerance for positioning scope)
③ After adjustment is done, apply the supper-glue to both B58.
■ Tolerance for 2
nd
mirror position
(Using with the mirror positioning scope)
1st mirror
B58
2nd mirror
1mm hole
OK OK NG NG
（
Standard
）
Scale
Center of Standard
12
- 2 - 1
2
1
-
1
-
2
12
-
2-1
2
1
-1
-2
NG: 0.8(X) or over
NG: 0.6(Y) or over
：Tolerance of 1 mm hole
（X-axis=±0.6、Y-axis=±0.8）

Pentax K100D Specifications

General

Megapixel	6.1 MP
Sensor type	CCD
Interface	USB 2.0
Color depth	8 bit
Digital SLR	Yes
Video capability	No
Camera shutter speed	1/4000 - 30 s
Focus	TTL
Auto focusing (AF) modes	centre weighted auto focus, continuous auto focus, selective auto focus
Light metering	Centre-weighted, Spot
ISO sensitivity	200, 400, 800, 1600, 3200, Auto
Light exposure modes	aperture priority AE, auto, shutter priority AE
Compatible memory cards	sd
Display diagonal	2.5 \
Display resolution (numeric)	210000 pixels
Magnification	0.85X x
I/O ports	AV - NTSC/PAL
USB version	2.0
Product color	Black
Battery type	AA
Number of batteries supported	4
Flash modes	auto, Flash off, Red-eye reduction
Scene modes	beach, Candlelight, Children, Close-up (macro), Documents, Museum, Night, Night portrait, Portrait, Sunset, Landscape (scenery)
Photo effects	black&white, Sepia
White balance	Cloudy, daylight, flash, Fluorescent, manual, Shade, Tungsten
Camera shutter type	Electronic

Weight and Dimensions

Depth	70 mm
Width	129.5 mm
Height	92.5 mm
Weight	570 g
