Pentax K20D User Manual

161
Shooting Settings
6
2 Press the four-way controller
(4).
The White Balance screen appears.
3 Press the four-way controller (23) and set.
Set the main switch to | to display Digital Preview with the set White
Balance.
Fine-tuning White Balance is easier with Digital Preview.
Press the { button to save the background Digital Preview image.
4 Press the 4 button.
The camera is ready to take a picture with the set White Balance.
• Refer to p.163 for manual adjustment method.
• Preview is Digital Preview, regardless of the [30. Preview Method] setting in
the [A Custom Setting] menu.
• The camera automatically performs fine-tuning even when the light source is
specified. The color temperature of the light source is fixed when [12. WB
Adjustable Range] in the [A Custom Setting] menu is set to [Fixed].
• Because the light source changes when the flash discharges, you can set the
white balance for when the flash discharges. Select [AWB], [Unchanged] or
[Flash] in [11. WB when using flash] in the [A Custom Setting] menu.
5000K
5000K
5000K
White Balance
W h i t e B a l a n c e
Auto
A u t o
White Balance
Auto
Check
C h e c k
Check
OK
O K
OK
OK
Downloaded From camera-usermanual.com Pentax Manuals

Pentax K20D Specifications

General

Camera Type	Digital SLR
Sensor Type	CMOS
Sensor Size	23.4 x 15.6 mm
Resolution	14.6 MP
Continuous Shooting Speed	3 fps
Image Stabilization	Sensor-shift
Screen Size	2.7 inches
Screen Resolution	230, 000 dots
Storage Media	SD/SDHC
Dimensions	141.5 x 101 x 70 mm
Weather Sealing	Yes
Image Processor	PRIME (Pentax Real Image Engine)
Shutter Speed	30-1/4000 sec
Viewfinder	Optical (pentaprism)
Battery	Rechargeable Lithium-Ion battery
ISO Range	ISO 100 - 3200 (expandable to 6400)
