Pentax K20D User Manual

52
Getting Started
2
Adjusting the Viewfinder Diopter
Adjust the viewfinder to suit your eyesight.
If it is difficult to see the viewfinder image clearly, slide the diopter
adjustment lever sideways.
You can adjust the diopter from approximately –2.5m
-1
to +1.5m
-1
.
1 Look through the viewfinder and
point the camera at a white wall
or other bright and consistent
surface. Slide the diopter
adjustment lever left or right.
Adjust the lever until the AF frame in
the viewfinder is focused.
•The FP Eyecup is attached to the
viewfinder portion when camera leaves
the factory. Diopter adjustment is available
with the F
P Eyecup attached. However,
adjustment is easier with the eyecup
removed. To remove the FP Eyecup, press
in one side and pull it out in the direction of
the arrow.
To attach the F
P Eyecup, align it with the
groove on the viewfinder eyepiece and
push it into position.
• If it is difficult to see the viewfinder image clearly even if you set the diopter
adjustment lever, use the diopter correction lens adapter M. However, the
eyecup must be removed to use this adapter. (p.258)
AF frame
Downloaded From camera-usermanual.com Pentax Manuals

Pentax K20D Specifications

General

Camera Type	Digital SLR
Sensor Type	CMOS
Sensor Size	23.4 x 15.6 mm
Resolution	14.6 MP
Continuous Shooting Speed	3 fps
Image Stabilization	Sensor-shift
Screen Size	2.7 inches
Screen Resolution	230, 000 dots
Storage Media	SD/SDHC
Dimensions	141.5 x 101 x 70 mm
Weather Sealing	Yes
Image Processor	PRIME (Pentax Real Image Engine)
Shutter Speed	30-1/4000 sec
Viewfinder	Optical (pentaprism)
Battery	Rechargeable Lithium-Ion battery
ISO Range	ISO 100 - 3200 (expandable to 6400)
