Pentax K20D User Manual

50
Getting Started
2
Attaching the Lens
All camera exposure modes are available when using DA, D FA, FA J or
other lenses with an Aperture s (Auto) position. Some functions are
restricted when lenses are not set to the Aperture s position. Also see
“Notes on [36. Using Aperture Ring]” (p.251). Other lenses and
accessories will not be available with factory default settings. To allow
shutter release with lenses or accessories not listed above, set [36. Using
aperture ring] in the [A Custom Settings] menu. (p.75)
1 Check that the camera is turned off.
2 Remove the body mount cover
(1) and lens mount cover (2).
Be sure to put the lens down with the
lens mount side facing upward to
protect the lens mount from damage
after removal.
3 Align the red dots on the
camera and the lens, and
secure by turning the lens
clockwise until it clicks.
After attaching, turn the lens
counterclockwise to check that the lens
is locked in place.
Turn the camera off before attaching or removing the lens to prevent
unexpected lens movement.
Downloaded From camera-usermanual.com Pentax Manuals

Pentax K20D Specifications

General

Camera Type	Digital SLR
Sensor Type	CMOS
Sensor Size	23.4 x 15.6 mm
Resolution	14.6 MP
Continuous Shooting Speed	3 fps
Image Stabilization	Sensor-shift
Screen Size	2.7 inches
Screen Resolution	230, 000 dots
Storage Media	SD/SDHC
Dimensions	141.5 x 101 x 70 mm
Weather Sealing	Yes
Image Processor	PRIME (Pentax Real Image Engine)
Shutter Speed	30-1/4000 sec
Viewfinder	Optical (pentaprism)
Battery	Rechargeable Lithium-Ion battery
ISO Range	ISO 100 - 3200 (expandable to 6400)
