Before Using Your Camera
1
27
Viewfinder
1 AF frame (p.52)
2 Spot metering frame (p.98)
3 AF point (p.107)
4 Flash status (p.60)
Appears when flash is available and blinks when flash is recommended but
not set or is being charged.
5 Shutter speed (p.76)
Shutter speed when capturing or adjusting (underlined when shutter speed
can be adjusted with the front e-dial).
6 Aperture (p.77)
Aperture when capturing or adjusting (underlined when aperture can be
adjusted with the rear e-dial).
7 Focus indicator (p.56)
Appears when image is focused.
Blinks when the subject is not in focus.
8 Manual focus (p.110)
Appears when focus mode is \.
9 EV bar (p.94, p.100)
Shows the EV compensation values or difference between the appropriate
and current exposure values when Exposure mode is set to a.
1
4
5 6 7
810
141211
9
13 15 16
23
1
