Peri SKYDECK - PEP 20 with Base MP 50

78
PEP 20 N 260*
L = 1.51 – 2.60 m
PEP 20-300
L = 1.71 – 3.00 m
PEP 20-350
L = 1.96 – 3.50 m
PEP 20-400
L = 2.21 – 4.00 m
PEP 20-500
L = 2.71 – 5.00 m
2.10 35.3 35.3
2.20 35.3 35.3
2.30 35.3 35.3 35.3 35.3
2.40 33.2 35.3 35.3 35.3
2.50 31.0 35.3 33.8 35.3 35.3 35.3
2.60 29.5 35.3 30.9 35.3 35.3 35.3
2.70 27.8 35.3 28.7 35.3 35.3 35.3
2.80 26.5 33.7 27.0 35.3 35.3 35.3 35.3 35.3
2.90 25.6 29.8 25.6 34.7 35.3 35.3 35.3 35.3
3.00 23.7 26.7 24.4 31.2 34.0 35.3 35.3 35.3
3.10 21.6 23.9 23.5 28.0 31.9 35.3 35.3 35.3
3.20 22.4 25.5 30.2 35.3 35.3 35.3
3.30 20.7 23.2 28.8 35.3 35.3 35.3 35.3 35.3
3.40 19.3 21.2 27.6 33.2 34.7 35.3 35.3 35.3
3.50 17.5 19.2 26.2 29.8 32.9 35.3 35.3 35.3
3.60 24.6 27.8 31.3 35.3 35.3 35.3
3.70 22.9 25.3 29.9 34.3 35.3 35.3
3.80 21.3 23.5 28.2 31.8 35.3 35.3
3.90 19.8 21.9 26.5 29.1 35.3 35.3
4.00 18.3 20.1 24.8 26.9 35.3 35.3
4.10 23.2 25.3 35.3 35.3
4.20 21.8 23.5 35.3 35.3
4.30 20.4 22.1 34.6 35.3
4.40 19.1 20.6 32.7 35.3
4.50 17.8 19.2 30.7 33.2
4.60 28.4 31.2
4.70 27.2 29.1
4.80 25.7 27.6
4.90 24.3 26.0
5.00 23.1 24.6
5.10 21.9 23.3
5.20 20.8 22.1
5.30 19.7 20.9
5.40 18.5 19.4
5.50 17.6 17.7
A18 Slab props
PEP 20 with Base MP 50
Permissible prop load [kN] according to the type test
Overall height [m] (prop extension + 50 cm)
Outer tube
bottom
Inner tube
bottom
Outer tube
bottom
Inner tube
bottom
Outer tube
bottom
Inner tube
bottom
Outer tube
bottom
Inner tube
bottom
Outer tube
bottom
Inner tube
bottom
*For the N Props, use of the inner tube
at the bottom is only possible in
connection with PERI Slab Tables or
SKYDECK (bolted head).
