Peri SKYDECK - PEP 30 with Base MP 50

80
PEP 30-250
L = 1.46 – 2.50 m
PEP 30-300
L = 1.71 – 3.00 m
PEP 30-350
L = 1.96 – 3.50 m
PEP 30-400
L = 2.21 – 4.00 m
2.00 41.6 41.6
2.10 41.6 41.6
2.20 41.6 41.6
2.30 38.9 41.6 41.6 41.6
2.40 36.1 41.6 41.6 41.6
2.50 33.9 41.6 41.6 41.6 44.1 44.1
2.60 32.2 41.0 41.6 41.6 44.1 44.1
2.70 30.8 38.7 41.6 41.6 44.1 44.1
2.80 29.7 35.3 40.3 41.6 44.1 44.1 40.3 40.3
2.90 27.5 31.3 38.3 41.6 4 4.1 44.1 40.3 40.3
3.00 25.9 27.6 36.5 41.3 4 4.1 44.1 40.3 40.3
3.10 35.1 40.0 44.1 4 4.1 40.3 40.3
3.20 32.9 36.8 43.8 44.1 40.3 40.3
3.30 31.1 33.2 41.7 44.1 40.3 40.3
3.40 28.5 30.3 38.8 41.8 40.3 40.3
3.50 26.1 27.1 37.1 39.7 40.3 40.3
3.60 34.8 36.5 40.3 40.3
3.70 32.4 33.5 40.3 40.3
3.80 30.0 30.9 40.3 40.3
3.90 27.8 28.7 40.3 40.3
4.00 25.6 26.3 39.4 40.3
4.10 36.7 37.9
4.20 34.3 35.2
4.30 32.0 32.9
4.40 29.9 30.5
4.50 27.6 28.2
A18 Slab props
PEP 30 with Base MP 50
Permissible prop load [kN] according to the type test
Outer tube
bottom
Inner tube
bottom
Outer tube
bottom
Inner tube
bottom
Outer tube
bottom
Inner tube
bottom
Outer tube
bottom
Inner tube
bottom
Overall height [m] (prop extension + 50 cm)
SKYDECK Panel Slab Formwork
Instructions for Assembly and Use – Standard Configuration
