Peri SKYDECK - PEP Ergo E

83
PEP Ergo E-300
L = 1.96 – 3.00 m
PEP Ergo E-400
L = 2.51 – 4.00 m
2.0 50.4 50.4
2.1 50.4 50.4
2.2 50.4 50.4
2.3 50.4 50.4
2.4 50.4 50.4
2.5 48.9 50.4
2.6 46.2 50.3 50.4 50.4
2.7 44.4 48.8 50.4 50.4
2.8 42.5 46.7 50.4 50.4
2.9 40.5 44.0 50.4 50.4
3.0 38.0 39.6 50.4 50.4
3.1 50.4 50.4
3.2 50.4 50.4
3.3 50.4 50.4
3.4 50.4 50.4
3.5 48.1 50.4
3.6 45.4 50.4
3.7 42.1 47.4
3.8 39.1 43.7
3.9 36.2 39.8
4.0 33.1 35.3
A18 Slab props
PEP Ergo B
Permissible prop load [kN] according to type test
Extension length [m]
Outer tube
bottom
Inner tube
bottom
Outer tube
bottom
Inner tube
bottom
Note:
■
PERI PEP Ergo E-300 and PEP Ergo E-400 Props fulfil
Prop Class E load-bearing capacity requirements of
DIN EN 1065.
■
General Building Inspectorate Approval Z-8.311-941
of the German Institute for Building Technlogy (DIBt).
SKYDECK Panel Slab Formwork
Instructions for Assembly and Use – Standard Configuration
