Peri SKYDECK - Internal forces and rigidity; Load combinations

15
061100 16.0 22.0 1198
061160 12.6 22.0 1198
061110 11.3 18.0 656
061045 2.9 8.0 91
061045 2.1 8.0 31
061047 3.0 8.0 88
061047 2.1 8.0 28
061049 0.7 2.4 32
061049 0.4 1.7 7
061050 0.6 2.4 29
061050 0.3 1.3 7
SKYDECK Paneel Deckenschalung
Aufbau- und Verwendungsanleitung – Regelausführung
A3 System dimensions
Internal forces and rigidity
Permissible internal forces and rigidity for the design with single-span girders
Table A3.01
Load combinations
Vertical loads
Concreting
(according to DIN EN 12812)
SKYDECK dead load Q
1
= 0.20 kN/m²
Concrete load Q
2,b
= 24.5 kN/m³ x d [m]
Equivalent load concreting Q
4
= 0.10 x Q
2,b
0.75 kN/m² ≤ Q4 ≤ 1.75 kN/m²
Equivalent load working
conditions Q
2,p
= 0.75 kN/m²
Total load Q = Q
1
+ Q
2,b
+ Q
2,p
+ Q
4
SKYDECK Platforms SDB
(according to DIN EN 12811)
Load Class 2 q
1
= 1.50 kN/m²
F
1
= 1.50 kN (500 x 500 mm²)
Horizontal loads
Horizontal load from working operations = 1% of the vertical load (DIN EN 12812; 8.2.2.2)
Horizontal load from the tilting position = 1% of the vertical load (DIN EN 12812; 9.3.4.2)
Wind loads
Working wind dynamic pressure q
W,A
= 0.20 kN/m² (DIN EN 12811-1; 6.2.7.4.2)
Maximum wind speed dynamic pressure q
W,max
= 0.60 kN/m²
Height of the substitute area for equipment and materials on the scaffold level
LF working wind h
W,A
= 0.40 m (DIN EN 12811-1, 6.2.7.4.2)
Height of the substitute area for equipment and materials on the scaffold level
LF maximum wind speed h
W,max
= 0.20 m (DIN EN 12811-1, 6.2.7.4.1)
Wind on the side protection
Working wind speed on SKYDECK Guardrail Holder SGH and Guardrail Post SGP
q
W,A,S
= 0.183 kN/m
Maximum wind speed with SKYDECK Guardrail Holder SGH and Guardrail Post SGP
q
W,max,S
= 0.550 kN/m²
Item no. Designation
perm. M
[kNm]
perm. Q
[kN]
El
[kNm
2
]
Main Beam SLT 225
Main Beam SLT 375
Main Beam SLT 150
Edge Beam SRT-2 150
Edge Beam SRT-2 turned
Edge Beam SRT-2 / 27
Edge Beam SRT-2 / 27 turned
Filler Timber SPH 150
Filler Timber SPH turned
Filler Timber SPH / 27
Filler Timber SPH / 27 turned
