Technical Data
12
3.02 PFAFF 1593
Stitch type: ..........................................................................................................301 (lockstitch)
Needle system: .................................................................................................................... 134
Model BN5: ...................................................... for the machining of medium-weight materials
Needle size in 1/100 mm:
Model BN5: .....................................................................................................................90 -110
Stitch length max ...........................................................................................................5.0 mm
Speed max.:
Model BN5 ................................................................................................. 3500 stitches/min
Clearance beneath the roller presser for a diameter of 30 mm: .......................................7 mm
Clearance beneath the roller presser for a diameter of 25 mm and 35 mm: ..................12 mm
Passage width: ..............................................................................................................245 mm
Clearance height: .......................................................................................................... 115 mm
Post height ....................................................................................................................180 mm
Bed plate dimensions: ................................................................................................518 x 177
Sewing head dimensions
Length: .............................................................................................................approx. 562 mm
Width: .............................................................................................................. approx. 250 mm
Height (above table): ........................................................................................approx. 505 mm
Motor data: .................................................................................. see motor specifi cation plate
Noise data
(Noise measurement in accordance with DIN 45 635-48-A-1,ISO 11204, ISO 3744, ISO
4871)
Emissions sound pressure level in the workplace at n = 2800 min
-1
: .............L
pA
= 80 dB(A)
)
Net weight of sewing head: ..................................................................................approx. 64 kg
Gross weight of sewing head: .............................................................................. approx. 74 kg
Subject to alterations.
Depending on the material, workstep and stitch length.
K
pA
= 2,5 dB
