Pfaff 1591 - Inserting the Sewing Machine into the Stand

Set-up and Initial Start-up
23
8.01.02 Inserting the sewing machine into the stand
 The hinges 1 are screwed to the sewing head base plate.
 Insert the sewing machine into the table top.
 Insert the sewing head support 2 into the table top hole.
Do not operate the machine without the support 2!
Risk of damage due to the top-heavy sewing head!
Machine can tip over backwards when moving it!
Fig. 8 - 02
1
1
2
