Maintenance and Care
74
Switch off the machine!
Risk of injury due to accidental
machine start-up!
In addition, add a few drops of oil onto
the hook race at the initial start-up or if
the machine has been standing still for a
prolonged period of time (see arrow).
Only use oil with a centre vis-
cosity of 22.0 mm²/s at 40 °C
and a density of 0.865 g/cm³ at
15 °C!
We recommend
PFAFF sewing machine oil
Order no. 280-1-120 144.
12.03 Oiling the hook
Fig. 12 - 02
Check the oil level before every
start-up.
Oil must always be visible in
the sight glasses 1 and 2
Add oil through the respective hole
above the sight glasses as needed.
Only use oil with a centre viscosity of 22.0 mm²/s at 40 °C and a density
of 0.865 g/cm³ at 15 °C!
We recommend PFAFF sewing machine oil, order no. 280-1-120 144.
Fig. 12 - 03
1
2
12.04 Checking the oil level of the hook and front parts
