Safety
9
Fig. 1 - 01
1.06 Danger warnings
A work area of 1 m must be kept free in front of and behind the machine to en-
sure unobstructed access at all times.
Do not reach into the needle range during the sewing operation! Risk of injury
from the needle!
Do not allow any objects to be placed on the table during the adjustment work!
The objects could become jammed or be slung away! Risk of injury from parts
fl ying around!
Do not operate the machine without the take-up lever guard 1!
Risk of injury due to the motion of the take-up lever!
Do not operate the machine without the belt guard 2!
Risk of injury due to the rotating driving belt!
Do not operate the machine without the anti-tipping device 3!
Risk of injury from crushing between the sewing head and the table top!
Do not operate the machine without the support 4!
Risk of damage due to the top-heavy sewing head!
Machine can tip over backwards when moving it!
1
2
3
4
