Pfaff 1591 User Manual

Maintenance and Care
76
12.08 Cleaning the blower air fi lter
 Remove the cover 1.
 Remove the fi lter element and blow it
out with compressed air.
 Insert the cleaned fi lter element and fi t
the cover 1.
Fig. 12 - 07
1
12
.07 Lubricating the roller presser drive gear mechanism (only for a diameter of 25 mm and 35 mm)
Switch off the machine!
Risk of injury due to accidental
machine start-up!
 Loosen the screws 1.
 Remove the cover 2.
 Lubricate the gear mechanism.
 Fit the cover 2 again.
 Tighten the screws 1.
Only use grease with a dripping
point of approx. 150 °C!
We recommend PFAFF sodi-
um soap grease with a dripping
point of approx. 150 °C.
Order no. 280-1-120 243.
Fig. 12 - 06
1
2
