S
et-up
36
9
.07
Setting stitch lengths
The f
eed motion of the roller presser and f
eed wheel can be c
hanged directly in manual
sewing and in the fi
xed programs
1
and
2
.
Switc
h the mac
hine on.
Call up the stitc
h length input menu.
Change the f
eed motion for the roller presser and f
eed wheel individually
.
or
Change the f
eed motion for the roller presser and f
eed wheel at the same time.
Conclude the input.
35
37
