Operating Controls
17
7.03 Bobbin thread monitoring using stitch counting
The diode 1 fl ashes on reaching the pre-
defi ned stitch count.
The stitch counting re-starts after trim-
ming the thread and changing the bob-
bin.
For presetting the stitch count
please refer to chapter 9.09
Switching on / setting the
bobbin thread monitoring us-
ing stitch counting.
Fig. 7 - 03
1
7.04 Pedal
With the main switch turned on
0 = Neutral position
+1 = Sewing
-1 = Raise roller presser
-2 = Trim thread
Other pedal functions can be
set through the programming,
see chapter 10 Sewing.
0
-2
-1
Fig. 7 - 04
+1
