S
et-up
34
9
.05
Threading the needle thread / adjusting the needle thread tension
Switc
h of
f the mac
hine!
Risk of injur
y due to accident
al mac
hine st
art-up!
Thread the needle thread as sho
wn in Fig
.
9
-
05
. Please ensure that the needle is thread-
ed from
left
to
right
.
Adjust the needle thread tension b
y t
urning the knurled thumb screw
1
.
Fig. 9 - 05
+
-
1
33
35
